Features
1 imported linear square rails, double four ball slider, loading capacity, smooth operation and long life. Imported ball screw, high accuracy, precision knife.
2 using high-precision rack and pinion, speed and high accuracy.
3 completely out of the computer with the USB interface can be remotely operated DSP operating system, handle operation, the operation easier and more user-friendly design, a unique intelligence budget rules, full electrical potential to achieve high speed processing, linear synchronous, the curve more perfect, not accounting for computer memory and enables the automatic start and stop cutting spindle.
4 software compatibility, support type3 / Actcam / Castmate / Wentai and other CAD / CAM design software.
5 Optional leading international technology vacuum adsorption countertops, with a strong adsorption force pump, the six district design, can be strong adsorption of materials of different sizes.
6 high-speed drive stepper motor and drive, Y axis used dual-motor drive, with vigorously cutting spindle carving faster.

Performance parameters
XY itinerary:
XY .Working Area
1600 * 2500mm
Z axis travel:
Z Working Area
> 150mm
Travel speed:
Working Speed
4-12m * min
Spindle power:
Spindle Power
3KW
Carved columns:
Engraving column
300 * 2000mm
Drive mode:
Drive System
Stepper / servo
Operating Voltage:
Working voltage
AC380V
