Features
1. The machine seamless welded steel structure, after a giant planer processing, solid shape, bearing strong, deformation, durable.

2. The three-axis imported linear guide, XY axis high speed rack and pinion drive, Z axis use imported ball screw, smooth operation, high precision carving.

3. On-line computer Weihong control system that uses a unique intelligent budget rules, full electrical potential to achieve high speed processing, linear synchronous, the curve is more perfect.

4. With breakpoints, breakpoint continued carving capabilities, with automatic error correction back to the origin, effectively ensure accuracy and then work long hours when.

5. Software compatibility, compatible type3 / Actcam / Castmate / CAD / CAM / Wentai and other design software.

6. This machine is an economical low-processing units, main electrical parts adopt international leading member.

Performance parameters
X stroke
1600mm
Y travel
1800mm
Z travel
150mm
Precision
0.05mm
Repeatability
0.01mm
Mesa structure
Vacuum adsorption
X, Y, Z structure
Taiwan is still the silver side rails XY Z screw
Since the consumption power machine
1.5KW
Drive mode
Servo
Operating Voltage
AC380V / 50HZ three electricity
G code
G-code
Spindle power consumption
1.5KW water-cooled spindle
